Jib Crane Models
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is connected to a pivoting vertical member and up to 20 feet long. Jib cranes could transport loads between any areas within the boom's arc of rotation. Light duty models are used in warehouses and factories for loads weighing up to 5 tons. The web site BestJibCranes.com features the major jib crane types as being either wall-mounted, mast mounted or free-standing.
Free Standing
Free-standing jib cranes are able to stand alone not requiring support from the building structure. The horizontal boom in this case is connected to a pivoting vertical column that is anchored firmly to the floor of the building. This kind of jib crane can rotate a full 360 degrees and needs a foundation made of either steel or concrete.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the bottom and the top. These pivots are connected to the floor of the building and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the advantage of not requiring the massive foundation required for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom that is connected to the wall of a building as opposed to the typical vertical column. These equipments are great in areas where the full 360 degree rotation is not required and provide up to 200 degrees of rotation.
There are two model varieties, depending on how the boom is supported. One of the kinds utilizes a tie rod that is attached from above the wall to the boom. The other type supports the boom from below by utilizing a cantilever brace which is attached to the wall too.
